Transparent LED Film Screen Circuit material,2Layer PET Copper Film

 About Transparent LED Display

The transparent LED display screen, as the name implies, has the property of transmitting light like glass.

It has a permeability of 50 to 90 percent, and the panel thickness is only about 10mm. Its high permeability is closely related to its special material, structure and installation method.

The principle of transparent LED display is a micro-innovation of LED light bar screen.

Targeted improvements have been made to the patch manufacturing process, lamp bead packaging, and control system.

*The biggest features of the LED transparent display circuit made of Topnano 2Layer FCCL are as follows:

1. There is no need for a hollow box structure design behind the display screen.
2. The intermediate circuit adopts flexible FPC circuit manufacturing process.
3. The transparent LED display module can be directly attached to the smooth glass surface.
4. The overall LED film screen module is quite light and has higher permeability.
5. The overall module saves human time and effort during transportation and erection.
6. The image quality presented is better and clearer.



PET Film with Copper Layer: PET (Polyester) film, known for its transparency and excellent mechanical properties, can be combined with a copper layer to create a highly conductive, flexible circuit material. This combination not only retains the transparency of PET film but also provides the electrical conductivity of copper, making it an ideal material for LED transparent displays.

Transparent LED Display: LED film screens, or transparent LED displays, leverage the transparency of PET film, making the screen nearly invisible when not in use. This unique feature allows it to be applied directly to glass surfaces, maintaining the glass's transparency. It's a popular choice for building glass facades, exhibition displays, and vehicle window advertising.

Flexibility and Lightweight: The inherent flexibility of PET film enables LED film screens to bend and roll, providing significant installation flexibility. Additionally, their lightweight and thin design make them easy to integrate into various applications.

Applications: This technology is widely used in advertising displays, interior decoration, stage design, and other areas where transparency and display capabilities are both required.

The PET Film with Copper Layer technology offers a combination of transparency, flexibility, and high conductivity, making LED transparent displays highly versatile for a broad range of applications.

Quick Details
Place of Origin: TAIWAN

Type: Metallized Copper Film

Base Material: Optical grade PET Film

PET Substrate's thickness: 50um / 125um

Copper Thickness: 2um~18um

Width of roll: 500mm

For Transparent LED Usage, customer generally choose Single Side PET with 2um~16um copper layer film.

Other product applications of this material:
Flex PCB, 5G antenna material, eTag application,Transparent Heating Film...
